Crimping machine
TYPE CM145D

Benefit:
- Precision Digital Control
- Quick Change Tool and Die rack
- Designed for Mass Production
- Energy Saving and Safety Operation
- Germany Made Voith Silent Pump
- CE Approved

Main Specification CM145D
Max Hydraulic Hose 2’’ 6SP or 4’’ Industrial Hose
Crimping Range mm 4-124
Die Type P32
Master Die Length mm 110
Max Opening mm +80
Motor KW 7.5KW by SIEMENS
Crimping Force KN 5000
Crimpings Per Hour 2500
Control Digital Control System
Pump By Voith Made in Germany
Pump Typ Silent Pump
Valve Rexroth Made in Germany
Foot pedal Included
Die Rack Included
Quick Change Tool Included
Backstop Device Optional
Mirror Standard
Control by Pressure Optional
Noise Level dBA 60
Protection Class IP56
L*W*H mm 900*700*1700
Weight KG 1300


Standard Die Sets Included:

Die No. 10* 12* 14 16 19 22 26 30 34 39 45 51 57 63 69 74* 78*
Length 60 60 60 60 60 75 75 75 80 80 90 90 100 100 100 110 110
Die No. 84 92 100 108 116
Length 120 120 120 120 120
* Special Die sets or dedicated die sets for RYCO PARKER Manuli Eaton hose available upon request
