PFA Pure Water Spray Gun - PDIG

PFA Pure Water Spray Gun - PDIG

The PFA pure water spray gun PDIG is designed for high-purity semiconductor applications and is widely used as an accessory for semiconductor cleaning equipment. The design adopts an ultra pure PFA spray gun body, and the material of the liquid passing parts is PFA or modified PTFE material, which can keep pure water away from metal ions. The sealing parts are precision machined, combined with specially designed diaphragms and valve cores, without the need for sealing rings, reducing dead corners while maintaining smooth and flexible product operation. The product is equipped with detachable hangers, making it easy to hang and simple!

Features:

1. High purity PFA material body, strong corrosion resistance, avoiding metal ion precipitation

2- Great temperature resistance, can be used for hot water

3- Compact and lightweight, easy to operate

Working temperature: -17 ℃ -93 ℃

Environmental temperature: -17 ℃ -66 ℃

Maximum operating pressure: 5Bar

Body Connection method: FNPT 1/4" (Flare type adaptor can be provided, please contact our sales representative for details)
