TYPE DFN - DIN Female fitting with smooth hose shank with nut

TYPE DFN - DIN Female fitting with smooth hose shank with nut

  • TYPE FL - Hose Fittings

    TYPE FL - Hose Fittings

    Shank standard: EN 14420-2 / DIN 2817.Assembly: safety clamp.Other flange standards are available.Other materials are av...

  • TYPE CS - Hose Fittings

    TYPE CS - Hose Fittings

    Fittings standard: DIN 2828.Assembly: safety clamp.Other materials are available.Remark: Can be customized.

Female fitting with smooth hose shank with nut
Fitting standard: DIN11851
Shank standard: EN14420-5/DIN2817
Nut material: SS304
Assembly: safety clamp
Other materials are available.

Remark: Can be customized.

Part no. Material Size For hose Thread Weight
mm Kg/pcs
DFN013S6LS4 SS316L+SS304 1/2" 13 RD 34 x 1/8" 0.22
DFN019S6LS4 SS316L+SS304 3/4" 19 RD 44 x 1/6" 0.28
DFN025S6LS4 SS316L+SS304 1" 25 RD 52 x 1/6" 0.37
DFN032S6LS4 SS316L+SS304 1-1/4" 32 RD 58 x 1/6" 0.44
DFN038S6LS4 SS316L+SS304 1-1/2" 38 RD 65 x 1/6" 0.55
DFN040S6LS4 SS316L+SS304 1-1/2" 40 RD 65 x 1/6" 0.67
DFN050S6LS4 SS316L+SS304 2" 50 RD 78 x 1/6" 0.76
DFN063S6LS4 SS316L+SS304 2-1/2" 63 RD 95 x 1/6" 1.4
DFN065S6LS4 SS316L+SS304 2-1/2" 65 RD 95 x 1/6" 1.46
DFN075S6LS4 SS316L+SS304 3" 75 RD 110 x 1/4" 1.89
DFN080S6LS4 SS316L+SS304 3" 80 RD 110 x 1/4" 2.1
DFN100S6LS4 SS316L+SS304 4" 100 RD 130 x 1/4" 2.89
