Drum Distribution Joints - DDJA/DDJC



It is a specialized joint designed to achieve safe and efficient distribution of high-purity chemicals from the drum. It only requires one opening of the drum to simultaneously solve the problems of liquid discharge and air intake (or exhaust). At the same time, the joint contains a check valve, effectively achieving drip free barrel replacement. More importantly, the use of chemical distribution joints can reduce the risk of operator errors and the duration of chemical exposure, providing protection for both operators and chemicals. This chemical distribution joint scheme is widely used in fields such as electronic grade chemical engineering, photovoltaics, semiconductors, high-purity raw materials, especially in acid supply systems. It can be compatible with intubation products from CPC and AS.

Features:

Safety, Minimize the possibility of leaks and minimize the impact of chemical fumes on operators and the environment

Efficient and convenient, stable and controllable traffic; Simple nut design, easy installation, and easy drum replacement.

Durability, Durable and able to withstand harsh operating conditions.

Corrosion resistant high-purity material, will not affect the medium and meets food grade standards

Different bodies, pipes, and sealing materials can be used according to specific needs.

Size / Material

DCA (AS)

DDJC (CPC)

Height (mm)

205

200

Width (mm)

80

75

Male thread diameter (mm)

41.5

35.5

Small sealing ring (mm)

15*3

19*2.5

Middle sealing ring (mm)

28.17*3.53

-

Large sealing ring (mm)

37.8*3.1

32.92*3.53

Liquid end size (inch)

3/4"or 1"flare

3/4" or 1"flare

Gas end size (inch)

3/8" or 1/2 "flare

3/8" or 1/2 "flare

Body (material)

HDPE/UPE/PTFE

Material of liquid end connector   (material)

HDPE/UPE/PTFE

Material of gas end connector (material)

HDPE/UPE/PTFE

Check valve core  (material)

PVDF/PFA

Sealing ring (material)

FKM/FFKM
