TYPE DM - Hose Fittings

TYPE DM - Hose Fittings

  • TYPE FLT - Hose Fittings

    TYPE FLT - Hose Fittings

    Fixed flange with toothed hose shank for connect with another hose closely, no easy to drop.Other flange standards are a...

  • TYPE SFN - Hose Fittings

    TYPE SFN - Hose Fittings

    Female fitting with smooth hose shank with nutFitting standard: SMSShank standard: EN14420-5/DIN2817Nut material: SS304A...

Male fitting with smooth hose shank without nut
Fitting standard: DIN11851
Shank standard: EN14420-5/DIN2817
Assembly: safety clamp
Other materials are available.

Remark: Can be customized.

Part no. Material Size For hose Thread Weight
mm Kg/pcs
DM013S6L SS316L 1/2" 13 RD 34 x 1/8" 0.10
DM019S6L SS316L 3/4" 19 RD 44 x 1/6" 0.14
DM025S6L SS316L 1" 25 RD 52 x 1/6" 0.24
DM032S6L SS316L 1-1/4" 32 RD 58 x 1/6" 0.32
DM038S6L SS316L 1-1/2" 38 RD 65 x 1/6" 0.38
DM040S6L SS316L 1-1/2" 40 RD 65 x 1/6" 0.40
DM050S6L SS316L 2" 50 RD 78 x 1/6" 0.41
DM063S6L SS316L 2-1/2" 63 RD 95 x 1/6" 0.89
DM065S6L SS316L 2-1/2" 65 RD 95 x 1/6" 0.91
DM075S6L SS316L 3" 75 RD 110 x 1/4" 1.35
DM080S6L SS316L 3" 80 RD 110 x 1/4" 1.43
DM100S6L SS316L 4" 100 RD 130 x 1/4" 1.84
