TYPE SSPET - Food Grade Composite Hose

TYPE SSPET - Food Grade Composite Hose

TYPE SSPET
Food Grade Composite Hose

Construction:
Internal helix: Stainless steel
External helix: Stainless steel
Inner tube: PET (Polyethylene terephthalate)
Cover: Polyester woven coated fabric
Temp. Range: -30°C to + 120°C
Application: This anti-static composite hose is designed for suction and discharge use on plant or road/rail tankers with a wide range of hydrocarbons where 100% aromatic resistance is required. The hose construction is exceptionally lightweight and flexible for ease of handling yet remains robust, hard-wearing and cost effective. Electrically resistant to less than 10 ohms.
Standard/Approval: GB 4806.7-2016, GB 9685-2016
Part No. ID Bending Radius Working Pressure Bursting Pressure Length
in. mm mm bar bar m
SSPET025 1" 25 100 16 64 40
SSPET038 1-1/2" 38 112 16 64 40
SSPET051 2" 51 150 16 64 40
SSPET065 2-1/2" 65 190 16 64 40
SSPET076 3" 76 225 16 64 40
SSPET102 4" 102 350 16 64 40
SSPET152 6" 152 600 16 64 20
SSPET203 8" 203 850 16 64 20
SSPET253 10" 253 1150 16 64 20
Remark: Working Pressure 10bar is available.
