Type JY10

Water cooling system hose for conveying purified water of the internal reduction electric furnace with a voltage of 10 KV


Applications:

It is suitable for conveying purified water through cable in induction electric furnace water cooling system with voltage of 10KV. Pure carbon - free, high insulation, wear - resistant, anti - aging.

Construction:

Tube: white, smooth, pure, carbon-free, high-insulated EPDM synthetic rubber.

Reinforcement: high strength polyester fiber.

Cover: white or green, pure carbon - free, high - insulation EPDM synthetic rubber. Smooth for ID1", fabric impression for ID1”.

Electrical resistance: high insulation, excellent low leakage current. At 10KV DC/AC voltage, the leakage current is less than 20 Micro Amp.

Temperature range: -40 °C +120 °C

Environmental standards: EU pahs-2, REACH, ROHS directive.

Technical standard: HG/T2184, CJAN

Part no.

ID

OD

Bending radius

Work pressure

Bursting pressure

Weight

Length

inch

mm

mm

mm

PSI

PSI

kg/m

m

JY10013

1/2"

12.7

22.0

100

300

1200

0.31

100

JY10016

5/8"

15.9

25.0

120

300

1200

0.35

60

JY10019

3/4"

19.0

29.0

150

300

1200

0.46

60

JY10022

7/8"

22.2

33.0

170

300

1200

0.58

60

JY10025

1"

25.4

38.0

200

300

1200

0.76

60

JY10032

1-1/4"

31.8

50.0

250

250

1000

1.1

40

JY10038

1-1/2"

38.1

56.0

300

250

1000

1.38

40

JY10042

42mm

42.0

60.0

336

250

1000

1.46

40

JY10045

45mm

44.5

62.5

360

250

1000

1.6

40

JY10050

2"

50.8

68.8

400

250

1000

1.9

40

JY10063

2-1/2"

63.5

81.5

500

200

800

2.5

40

JY10076

3"

76.2

94.2

600

150

600

3.2

40
