Sanitary Stainless Steel Pneumatic 3 pc Ball Valve

Sanitary Stainless Steel Pneumatic 3 pc Ball Valve

Sanitary Stainless Steel Pneumatic 3 pc Ball Valve
With Spring Actuator

Product Name:  3 Piece ball valve
 Valve Body Material:  SS304 or SS316L
 Seal Material:  Silicon, EPDM, PTFE,Viton, NBR
 Max. Working Pressure:  10Bar
 Max.Working Temperature:  120 degree C
 Availably  size:  DN15-DN100 or 1/2" - 4"
 Availably connection:  Weld, Clamp,  Female, Flange, or Combinations
 Inside SurfaceTreatment:  Ra≥0.4-0.8 um
 SurfaceTreatment:  Ra≥0.8-1.6 um
 Availably standard:  DIN,SMS,3A,RJT,IDF,ect.
 Operated type:  Manual,Pneumatic,Electric
 Certification:  ISO9001:2008,CE,3A
